Flex Circuit Manufacturing
Flexible Circuit Design, Manufacturing, & Assembly
Turn-Key Solutions For Single-Sided/Double-Sided Flexible Circuits
Using the latest flexible circuit equipment and strict quality-control rules, Green Circuits’ printed flex circuit capabilities can offer any business fast turnarounds on medium-volume orders. A leader in the printed flex circuit/rigid-flex circuits industry, Green Circuits has designed, fabricated, and assembled printed circuit boards for some of the biggest high-tech companies in the world. Green Circuits offers two types of printed flex circuit options: single-sided flexible circuits and double-sided flexible circuits.
Single-Sided Flexible Circuits
Single-sided flexible circuits are ideal for a number of situations, including unusual folding, forming, or dynamic applications. Consisting of a single copper-conductor layer on a flexible dielectric film, single-sided flexible circuits provide a unique type of printed circuit board for installation or service flexing. Single-sided flexible circuits can be fabricated with or without cover layers. The figure below breaks down the material makeup of single-sided printed flex circuit:
Single-Sided printed flex circuit features include:
- Ultra-thin construction under .004″-.008″ (.10mm-.20mm)
- 1 Conductor Layer
- Reverse bared or back bared pad
- Supported and unsupported finger areas
Double-Sided Flexible Circuits
Double-sided printed flex circuits gives designers another level of capability for more complex applications. When an application calls for high-density design and layout, double-sided printed flex circuits ensure a compact, efficient design ideal for such uses as ground and power plane applications. Double-sided flexible circuits can also be commonly found in shielding applications or on a dense surface-mount assembly. The figure below breaks down the material makeup of double-sided flexible circuits:
Double-Sided Flex Circuit Features:
- Component assembly available on both sides.
- Two conductive layers.
- Fingers are an integral part of the conductor patterns.
- Multi-layer Flex Circuits
- 3.3 mil Flex Circuits
About Green Circuits: An Experienced Electronic Manufacturing Service (EMS) Provider
Green Circuits is an experienced ITAR, ISO 13485 and AS-9100 Certified electronics manufacturer, specializing in quick-turn PCB design, prototype and production assembly. Green’s experts ensure product reliability and accuracy by performing thorough inspections and tests, using state-of-the-art equipment in our ESD-controlled facility. Green Circuits provides proactive communication with all product-involved teams throughout the manufacturing process, procurement of quality components from trusted supply chain partners and a thorough understanding of Industry Standards and custom manufacturing requirements.
Green Circuits enables firms of all sizes to improve their production cycle while reducing manufacturing time and costs by providing an array of turnkey manufacturing services to meet the unique requirements throughout all phases of your product’s life-cycle.
